Material Development and Structure Characterization

Renewable resources – Basis for new materials



Bio-based alternatives to traditional polymer systems based on petroleum chemistry, become more and more important in a variety of application fields. The limited availability of fossil resources, the dependence on oil and raw material-related netto emissions of carbon dioxide from burning of plastics are reasons to look for new ways to manufacture polymers from renewable resources. However, with respect to imported petroleum-based materials, marketable technical solutions for bio-based products must also offer advantages concerning properties or price. The application-oriented research activities of the department "Material Development and Structure Characterization" follow this aim.

Discover our versatile possibilities



Material Development

application-oriented R&D on thermoplastic materials, bio- and petro-based polymers, reinforcement via usage of cellulose and lignin

TO MATERIAL DEVELOPMENT


© Fraunhofer IAP

Structure Characterization

comprehensive chemical and physical structure elucidation

TO STRUCTURE CHARACTERIZATION


Carbonization

from precursor to carbon fiber, R&D on bio-based, new and classic precursor-systems, up to 3,000 °C

To Carbonization

Our services



contract research | research cooperation | development services | quality control | routine measurements | method development | consulting

Projects and publications

Resistance of bioplastics and biocomposites

Biogenic carbon materials for the enery transition

more information

We are here for you!

Your contact persons

Material development

Our team develops thermoplastics for your applications. We optimize polymer materials for your specific requirements. We adjust material properties according to your requirements. For this purpose, we modify, additivate and reinforce both petroleum-based and bio-based polymers. Our goal is to improve the physical, mechanical, thermomechanical properties of the materials, including processability.

Would you like to
manufacture your
products from
sustainable materials
or to develop
new materials?

Equipment

COMPOUND-MANUFACTURE

  • flexible configurable twin screw extruder up to 15 kg/h
  • conical twin screw extruder for  small amounts from 5 cm³
  • measuring kneader

FILMS

  • chill-roll systems
  • tools for cast and flat films
  • laboratory blown film line
  • monoaxial laboratory stretching system for films and fibers
  • thermoforming machine

INJECTION MOLDED PARTS

  • piston injection molding machine for small amounts
  • injection molding machines

Bio-based polymers and natural raw materials

  • cellulose- and starch derivatives
  • poly lactic acid (PLA)
  • polyhydroxyalkanoates
  • bio-based polyesters like PBS, PBAT
  • polyamides

Petro-based polymers



THERMOPLASTIC PROCESSING

  • reinforcement by cellulose, lignin and natural fibers
  • adjustment of biological degradation through the use of starch



We develop
biopolymers for
your applications

Our services for your success



  • specific design of material properties
  • substitution of petroleum-based components with bio-based materials
  • increase of the bio-based content in final products
  • manufacture of nano-composites
  • adhesion, additivation
  • elucidation of the relations between processing conditions, structures and material properties

Structure characterization

You want to understand your material, characterize it or check its quality? We analyze for you the relationships between the chemical and physical structure of your material and its properties. You benefit from the many years of experience of our staff in the fields of light and electron microscopy, X-ray diffraction and NMR spectroscopy. In addition, we offer state-of-the-art equipment for structural characterization. We effectively combine different methods to detect different levels of structure. In our climate-controlled testing laboratory, we use a wide range of mechanical testing methods to characterize material properties. We analyze melting and crystallization processes using thermal analysis methods.

Would you like
to understand
your material,
characterize it or
check its quality?

Electron microscopy

SEM and TEM

  • artefact-free depiction
  • special preparation techniques
  • morphological structure
  • study of high-swollen products
  • depiction of surfaces and cross-sections

X-ray diffraction

WAXS and SAXS

  • characterization of the super-molecular structure
  • determination of the degree of crystallinity and crystal dimensions
  • determination of the degree of orientation
  • characterization of cavity structures

© Fraunhofer IAP

Equipment

  • air-conditioned, mechanical laboratory for comprehensive mechanical studies from 10 mg to 2 t
  • differential scanning calorimetry (DSC)
  • dynamic mechanical analysis (DMA)
  • determination of material humidity
  • determination of the density of solids and liquids
  • vibroscope for determining the fiber fineness
  • permeation measurement devices regarding water vapor and oxygen
  • equipment for fire testing
  • light microscopy
  • polarizing microscopy

NMR-spectroscopy

SOLID-STATE-NMR

  • CP/MAS-method for analyzing solid native and synthetic polymers
  • chemical composition
  • super-molecular structure

LIQUID-STATE-NMR

  • measurement of various cores at different temperatures
  • characterization of the chemical structure of monomers, intermediate products and polymers
more info

Raman-spectroscopy

with microscope system

  • study of carbon allotropes
  • analysis of inclusions
  • 3d-mapping-images
  • excitation at 266, 532, 633 and 785 nm

Carbonization

We have been driving the development and production of carbon fibers for many years. Your advantage: You receive all competencies from a single source - starting from raw material pulping through polymer synthesis and fiber spinning to thermomechanical conversion of carbon fibers and further processing into carbon fiber reinforced plastics (CFRP). We advise, develop and optimize on your behalf. Fraunhofer IAP focusses on classic, new and especially on bio-based precursor systems. We develop fibers with customized geometries and properties. We also provide solutions to make manufacturing and processing processes more economical and ecological.

Do you want to test your precursor, carbon fiber or want to make them fit for the future? Discover our services.

Precursor conversion

  • on the basis of cellulose or cellulose derivatives
  • on the basis of lignin or lignin derivatives
  • hybrid material systems
  • PAN copolymer systems, textile PAN
  • melt spinnable systems

Research and development

  • evaluation of the process capability and of the carbon fiber potential for new and classical precursor systems
  • further development of classical precursor systems
  • additives and catalysts to increase efficiency and performance

Equipment

  • continuously tension- or elongation-regulated fiber transport
  • batch type furnaces up to 3,000 °C
  • horizontal continuous furnaces:
    stabilization up to 400 °C
    LT-carbonization up to 1,000 °C
    HT-carbonization up to 2,000 °C

Equipment

  • continuously tension- or elongation-regulated fiber transport
  • batch type furnaces up to 3,000 °C
  • horizontal continuous furnaces: stabilization up to 400 °C, LT-carbonization up to 1,000 °C, HT-carbonization up to 2,000 °C



Sustainable
carbon fibers

We offer you individual strategies and solutions to make your manufacturing and processing of carbon fibers more economical and ecological.

more Info

Biobased, novel and classical precursor systems or carbon fibers



We consult, develop and optimize on your behalf.





Projects and Publications

Read the latest press releases and learn more about our research projects.



Resistance of bioplastics and bio-composites

BeBio2

to the project


Biogenic carbon materials for the energy transition

CARBION

to the project


Circular Plastics Economy: Things are rolling smoothly for plastics

Press release | Sep 20, 2019

to the press release


Bio-based carbon fibers: performance and sustainability for light-weight applications

Press release | Oct 1, 2019

to the press release


New splint for bone fractures

Press release | July 2, 2019

to the press release


© Fraunhofer IAP

ILA 2018: Cost-effective carbon fibers for light-weight construction

Press release | Apr 18, 2018

to the press release
